Aquilion Prime SP
Complete Clinical Capability
The Canon Aquilion Prime SP is the CT system of choice for geological, research, and industrial quality-control imaging needs.
Built with premium technology migrated straight from our high-end CT, Aquilion Prime SP empowers your facility with a fast, efficient solution that makes their work easier.
We offer both new and refurbished options.
System Highlights:
- Up to 4 cm z-axis coverage
- 0.5 mm × 80 PUREViSION detector row
- PUREViSION Optics
- 0.35 sec rotation
- 72 kW Generator
- 78 cm gantry bore
- 70 cm extended field-of-view*
Key Benefits:
- Scalable to your needs
- Image more samples and do it faster¹
- Air cooled and can be installed in most existing CT rooms, avoiding costly renovations
*Optional
¹With SURE Technologies
CANON INDUSTRIAL CT
Aquilion Prime SP
The Canon Aquilion Prime SP brings next-generation CT imaging to veterinary practice, combining 320-detector row coverage, deep learning reconstruction, and an automated INSTINX workflow to deliver fast, consistent, and precise diagnostic results for patients of any size or complexity.
320-SLICE, CARDIAC, NEUROLOGICAL, LARGE & SMALL ANIMAL, DEEP LEARNING RECON, WIDE BORE
DETECTOR ROWS
320 rows
.5 mm each
ROTATION SPEED
.241 sec
Minimum rotation
GANTRY BORE
80 cm
Wide bore access
Z-AXIS COVERAGE
16 cm
Single rotation
GENERATOR
100 kw
Up to 1,400 mA
OVERVIEW
The pinnacle of industrial CT imaging
The Canon Aquilion ONE / INSIGHT Edition represents a new standard in veterinary diagnostic CT. Featuring a next-generation gantry and optical system, this platform leverages Canon’s latest Deep Learning Reconstruction technology (AiCE) combined with the PIQE 1024 detector matrix to bring clinical-grade precision and efficiency to veterinary imaging at every level of complexity.
Whether imaging a cat’s neurological structures or a large dog’s cardiac function, the INSIGHT Edition delivers consistent, high-quality results with dramatically reduced scan times, improving patient throughput and reducing the duration of anesthesia. Available in both new and remanufactured configurations to suit any practice size or budget.
Fastest rotation in class
.241-second minimum rotation enables cardiac and dynamic imaging previously not possible in veterinary CT.
320-row whole-organ coverage
16 cm z-axis captures entire organs like the brain, heart, and kidneys in a single rotation without table movement.
AiCE deep learning recon
AI-powered reconstruction delivers superior soft tissue contrast at reduced dose levels versus conventional algorithms.
INSTINX automated workflow
Automated scanning processes reduce variability and ensure consistent, repeatable exams across all staff levels.
TECHNICAL SPECIFICATIONS
System Specifications
Gantry
Gantry bore diameter
80 cm
Rotation speed
.241 seconds minimum
Gantry tilt
±30°
Maximum frame rate
80 fps
Gantry illumination
Included
Lateral side (Tech Assist)
17 cm (8.5 cm left or right)
Detector
Detector name
PUREINSIGHT
Detector rows
320 rows
Detector pitch
.5 mm
Z-axis coverage
16 cm
Matrix (PIQE Cardiac)
1024
Matrix (PIQE Body)
1024
X-Ray System
X-Ray tube
CoolNovus
Generator power
100 kW
Maximum mA output
Up to 1,400 mA
kV selection
70, 80, 100, 120, 135 kV
Dose reduction
SilverBeam filter (Ultra-low dose)
Reconstruction
AiCE Whole Body Deep Learning
Patient Couch
Couch weight capacity
315 kg / 695 lbs
Tabel motion
Motorized, bidirectional
Lateral slide
17 cm total (Tech Assist)
Compatible patients
Small to large animals
Installation
Minimum room size
19.38 m
Power requirements
Contact USD for site specs
Availability
New and remanufactured
Installation
Full site prep and commissioning by USD
CLINICAL APPLICATIONS
What this system is built for
The Aquilion ONE / INSIGHT Edition is suited for a wide range of veterinary clinical applications across companion animals and larger patients.
Cardiac imaging
Fast rotation and wide coverage enable complete cardiac studies in a single breath-hold equivalent scan cycle.
Neurological imaging
High-resolution brain and spinal cord imaging with PIQE 1024 matrix for detailed soft tissue differentiation.
Oncology studies
Whole-body coverage in a single pass supports comprehensive oncological staging and treatment planning.
Emergency & trauma
Sub-second scan times enable rapid whole-body trauma surveys for critically ill or injured patients.
